Self assembling tiles that make any kind of space structures ace first orbital tests


These re-configurable self-assembling space tiles make it possible to assemble almost any kind of structure in space autonomously.


Love the Exponential Future? Join our XPotential Community, future proof yourself with courses from XPotential Universityconnect, watch a keynote, read our codexes, or browse my blog.

What if you could just launch a bunch of flat pack into space and have it assemble itself in orbit? Well, up until recently the closest we got was 3D and 4D printing structures in space that self-assembled. Now though researchers at MIT Media Lab have tested modular tiles that autonomously assemble to create habitats in space on the latest mission to the International Space Station.


See also
SpaceX's SN15 Starship prototype finally sticks the landing


Called Tesserae, the project aims to create future space habitats from reconfigurable tiles that assemble while in orbit around the moon or Earth. MIT suggested the tiles can be used to form designs from “geodesic dome habitats, to microgravity concert halls, to space cathedrals.”


The Future of Space keynote, by Matthew Griffin


Each 3D printed tile is made of a rigid plastic outer shell with either five or six sides, with two indented holes for electromagnets. These magnets allow the tiles to autonomously “snap” or bond together to form tesselated structures – polyhedral, enclosed shapes that resemble a honeycomb.

The bonding is designed to be both watertight and weathertight, making the structures suitable for future human habitation, and each tile also has a system for power harvesting and management.


See also
Japan joins the race to mine the Moon


“I hope to apply the Tesserae technology to build an entirely novel type of space architecture – large scale structures that can inspire awe and delight their occupants,” said Ariel Ekblaw, director and founder of the Massachusetts Institute of Technology (MIT) space exploration initiative.

“We’re about to enter a renaissance moment for space architecture where in-space structures can both protect humans and bring joy,” she said.


See them in action


Ekblaw, who began developing the Tesserae technology during her PhD at MIT Media Lab, named the project Tesserae after the small, coloured tiles used in ancient Roman mosaics.

It is also an acronym for Tessellated Electromagnetic Space Structures for the Exploration of Reconfigurable, Adaptive Environments.

“We use bio-inspired processes like self-assembly and swarm robotics to explore a new paradigm for space architecture – building grand scale space structures in orbit,” Ekblaw said.


See also
Architects unveil plans for Dubai's Mars Science City and colonies on Mars


“Our tessellated shell structure approach proposes multifunctional tiles that assemble autonomously via magnetically-mediated bonding along regular, geometric edges.”

While the biggest prototype tiles are only a few inches in diameter, the at-scale Tesserae tiles will have a five-foot-long edge so that when combined, they will be able to house people.

Unlike many current outer space structures, which are often rigid and made on Earth before being transported, the Tesserae tiles can be applied to many shapes and come flat-packed before being deployed in space.

They can also disassemble autonomously.

“The team behind Tesserae believes that their modular, self-assembly method can lower payload weight and reduce construction complexity, while also broadening the possibilities of what future space architecture may look like,” explained Ekblaw.


See also
Virgin Orbit strapped a rocket to their 747 to democratise access to space


“As habitation and operation needs evolve around new commercial space stations in low earth orbit and exploration missions to the Moon and Mars, space architecture must adapt to address new use-case and deployment contexts.”

In June Tesserae was one of 25 experiments on Axiom’s private ten-day research mission to NASA’s astronomical and research centre, the International Space Station (ISS). While there astronauts released seven tiles into space and observed how they bonded together.

It was the first ever private ISS mission and was flown in partnership with SpaceX, the spacecraft manufacturer founded by Elon Musk. According to the mission’s findings, the tiles successfully fused together and will be trialled next in 2023.

“We’re delighted to report that we demonstrated successful good bonds, correct error detection and magnet pulse-off correction and a stable dome configuration,” said Ekblaw. “We expect to deploy our next, iterative spaceflight test in 2023 and will continue to work with collaborators towards our long term vision for human habitability.”
